Calculators and references for planning sheet and plate parts, so your drawing shows up ready to cut. Everything runs in your browser; nothing you type is sent anywhere.
Featured tool
Bend Deduction Calculator
Drag the flange to the angle you need and get the bend deduction and flat blank from LCNW’s own press-brake tables, with the part drawn to scale, bend allowance, setback, K-factor and the bend line from the edge.
- 1–147° bends
- in / mm switch any time
- Share a link to the exact bend
Blank weight & nesting
What does it weigh, and how many per sheet?
Rectangular blank, before holes and cutouts. Spacing is the web left between parts on the sheet.
96″ × 240″ sheet · 5 × 19 = 95 parts89% yield
| Sheet | Per sheet | Sheets for 50 | Yield |
|---|---|---|---|
| 15 | 4 | 70% | |
| 18 | 3 | 68% | |
| 27 | 2 | 81% | |
| 33 | 2 | 83% | |
| 95 | 1 | 89% |
Sheet gauge chart
Gauge to thickness
| Gauge | in | mm | lb/ft² | Use |
|---|---|---|---|---|
| 7 | 0.1793 | 4.55 | 7.32 | |
| 8 | 0.1644 | 4.18 | 6.71 | |
| 9 | 0.1495 | 3.80 | 6.11 | |
| 10 | 0.1345 | 3.42 | 5.49 | |
| 11 | 0.1196 | 3.04 | 4.88 | |
| 12 | 0.1046 | 2.66 | 4.27 | |
| 13 | 0.0897 | 2.28 | 3.66 | |
| 14 | 0.0747 | 1.90 | 3.05 | |
| 16 | 0.0598 | 1.52 | 2.44 | |
| 18 | 0.0478 | 1.21 | 1.95 | |
| 20 | 0.0359 | 0.91 | 1.47 | |
| 22 | 0.0299 | 0.76 | 1.22 | |
| 24 | 0.0239 | 0.61 | 0.98 | |
| 26 | 0.0179 | 0.45 | 0.73 |
Steel and galvanized: Manufacturers’ Standard Gauge. Aluminum: Brown & Sharpe. Mill tolerances apply, so call out a decimal thickness on the drawing when it matters.
Fraction · decimal · metric
Convert a dimension
- Decimal inch
- 0.1875″
- Nearest 1/64
- 3/16″
- Millimeters
- 4.76 mm
- Steel gauge
- —
LCNW Finish Classification
Put a class on the PO, get that surface.
Four classes decide how we handle, protect and finish your parts from the rack to the truck. If die marks aren’t acceptable and we need to form with die rubber, say so on the PO.
Class AArchitectural
No visible scratches or imperfections when viewed casually. Usually #4 stainless or sheet under laser vinyl that stays on; both sides may need to be clean.
Hot rolled steel can’t be guaranteed blemish-free.
Class BPolished or plated
Will be polished or plated for visible cosmetic use. Minor scratches that finishing hides are fine, as long as a fingernail doesn’t catch.
The fingernail test
Class CPowder coat ready
Will be powder coated, plated or DA sanded to a uniform look. Light scratches or scuffs that finishing removes are acceptable.
Most painted parts
Class DStructural
Machine or structural parts where looks don’t matter. Forklift marks and handling flaws are fine if strength isn’t affected.
Brackets, frames, weldments
Design to our shop
How big, how thick, what to send.
- One piece up to 8 × 20 ft. For anything bigger, ask us about splitting the part.
- Nest on stock sheets. See how many of your blanks fit on each stock sheet with the nesting tool above.
Thickest plate we cut
- Steel1.75″
- Stainless1.5″
- Aluminum1.5″
Down to thin gauge sheet for enclosures and trim. Ask about anything outside these.
Files we take
- DWG
- DXF
- STEP
- IGS
- SLDPRT
- JPG
- PNG
- XLSX
- CSV
- DOCX
- ZIP
- 3DM
DXF or STEP gets you the fastest quote. PDFs, sketches and phone photos work too. Up to 15 files, 100 MB each, straight from the quote form.
